Wet Grinder
Back
Technical Specifications
| Model | PCH-400/5/WET | PCH-500/5/WET | PCH-600/5/WET |
|---|---|---|---|
| Length of Blades | 400mm | 500mm | 630mm |
| No.of Blades | 5 | 5 | 5 |
| Throat Size | 400 x 400mm | 500 x 500mm | 630 x 630mm |
| Grinding Capacity | 80 TO 100Kg/hr | 125 to 130kg/hr | 175 to 200kg/hr |
| Power Required | 10HP (7.5KW) | 15HP (11.25KW) | 25HP (18.75KW) |
| Screen Area | 2100 Sq. Cm. | 3000 Sq. Cm. | 4800 Sq. Cm. |
| Additional Feature | Provided with 0.5HP screw conveyor to transfer the grinded material to bin & separate water from grinded material | Provided with 0.5HP screw conveyor to transfer the grinded material to bin & separate water from grinded material | Provided with 1HP screw conveyor to transfer the grinded material to bin & separate water from grinded material |
| Suitable for | One Stage grinding & washing of PET Bottles HDPE Bottles & Jars etc. | One Stage grinding & washing of PET Bottles HDPE Bottles & Jars etc. | One Stage grinding & washing of PET Bottles HDPE Bottles & Jars etc. |
Note
- Higher Models available on request.
Special Features
- Single step grinding and washing of soiled PET Bottle & Jars.
- Continuous water fall to keep the chamber cool.
- Easy Collection of grinded flakes at one end and discharge of dirty waste at the other end.
- Pressure washing ensures maximum cleaning of dirty waste in one cycle and saves power & labour too
- No dusting is observed during grinding as the same is absorbed by the water flowing.
- Suitable for Pet, HDPE.
