Overview
Plastic film recycling machines utilized to recover in-lineEdge trim or off-line rolls. The resultant densified chipProduced is easily recycled by blending it back in to theprocess Together with virgin material.
Technical Specifications
| Model | PRP - 150 | PRP - 250 |
|---|---|---|
| Max. Material Width (mm) | 400 | 600 |
| Max. Material Thickness (mm) | 0.05-0.5 | 0.05-0.5 |
| Roller Speed (mtr /min) | 0-150 | 0-250 |
| Power (HP) | 5HP(3.75KW) | 7.5HP(5.6KW) |
| Rotary Blade (Pcs) | ∅ 165 x 18T -1Pcs. | ∅ 280 x 28T- 1Pcs |
| Stationary Blade (Pcs) | 1 | 1 |
| Capacity(kg/hr) | 100-125 | 150-200 |
Note
- Higher Models available on request.
- Capacity depends on type of material, scrap size & shape.
Special Features
- Densified chips are immediately recycledwithout risk of contamination.
- In-Line and Off-Line process
- No colour degradation or secondary heat generation
- Immediate re-use of edge trims withoutthe need of storage or handling
- Low Energy Consumption
- A. C. Drive Control Systems
- Suitable for RPVC, PET, PS, HDPE, PP etc.
