Granulator - 300
Back
Technical Specifications
| Model | PCH - 300 | PCH - 300/5 | PR - 300 | PSTG - 300 |
|---|---|---|---|---|
| Length of Blades | 300mm | 300mm | 300mm | 140mm-6, 300mm-2 |
| No. of Blades | 4 | 5 | 6 | 8 |
| Throat Size | 300 x 300 mm | 300 x 300 mm | 300 x 300 mm | 300 x 300 mm |
| Grinding Capacity | 60 Kgs/Hr | 70 Kgs/Hr | 80 Kgs/Hr | 90 Kgs/Hr |
| Power Required | 5HP (3.75 KW) | 5HP (3.75 KW) | 5HP (3.75 KW)) | 5HP (3.75 KW) |
| Screen Area | 1150 Sq.Cm | 1150 Sq.Cm | 1150 Sq.Cm | 1150 Sq.Cm |
| Floor Space (L&W) in mm | 1100 x 950 | 1100 x 950 | 1100 x 950 | 1100 x 950 |
| Suitable for grinding | Buckets upto 5Ltrs. & Blow Containers upto 3Ltrs. | Pipes upto ∅60mm &Pet Bottles | Films Box strapping tapes | Small Lumps,Solid articles. |
Note
- Higher Models available on request.
- Capacity depends on type of material, scrap size & shape.
- PSTG series - Number of blades & output will depend on application.
- All specifications are subject to change without notice for constant product development.
- Control Box, Side Chute, Sucking blower attachments, Silo, Conveyor, Dust collector attachments are optional.
